SPECIFICATION Voltage DC 12V / 24V Maximum Current 60A Operating Temperature -40℉~185℉ / -40℃~85℃ Operating Power at 12V 720W Operating Power at 24V 1440W Waterproof IP65 (control box only) Electrification Modes & Switch Panel Backlight Constant Mode The switch panel keeps powering the device on. Usually used for windshield light bars, spot lights, fog lights for constant illumination. Strobe Mode The switch panel keeps powering the device on and off. Usually used for rock lights, light strips, interior lights or flashing signal. Momentary Mode The switch panel powers the device only when you press down the button. Usually used for horns. 8 Circuits with Triple Protection for 8 Devices Connect with safety. Each circuit has a built-in RELAY and a FUSE ranging 10A, 15A, 20A or 30A for devices with different working currents. Plus, there is an 80A CIRCUIT BREAKER to be connected between the control box and your car battery. (5 more spare fuses are included in package) Multifunctional Buttons & 140pcs Stickers There are 3 main buttons of power, color and brightness to control power status and 8 colors, 3 color changing modes and 5 brightness level of the panel backlight. Besides, they also serves to set the 3 electrification modes(constant, strobe, momentary) of the 8 devices. The package set includes 140pcs stickers to choose from to label the buttons.(Scroll down this page to check out the stickers) No need to fight with tangled wires anymore. This switch panel allows you to run only 1 wire in your cab and keep the rest in the engine bay. Note The length of the control wire connecting the panel and control box is about 137 inch. 5 Pieces of Brackets for 4 Mounting Ways #1: Panel can be fixed vertically. #2: Panel can be fixed to a plane and be able to rotate. #3: Control box can be fixed vertically. #4: Control box can be hung on a right angle plane. Note The width space needed for the brackets to install. #1: 6.1 inch. #3: 9 inch. #4: 8 inch. 140pcs Stickers and Wires Previous page Extra Stickers are Available Check it out Extra Stickers are Available Check it out Next page Set Includes Switch panel with control cable*1; Control box*1; Stickers*140; Mounting brackets*5; Power cables*5(positive*2, negative*1, ACC*2); Circuit breaker*1; Zip ties*10; Assembly accessories (screws and nuts); Spare fuses*5; User manual*1 Note: The mounting brackets are put under the foam in the package box. The spare fuses are attached in the control box.
